Product Description

4 "full-power" cook zones

Front-central: 1,200W 6'' (145mm) Booster: 2,000W

Back-right: 2,500W 11'' (270mm) Booster: 3,700W

Back-left: 1,800W 7 1/2" (180mm) Booster: 2,500W

Front-left: 2,500W 7 1/2" (180mm) Booster: 2,500W

Bridge zone: 15 5/32" x 9 1/16" (385x230mm) Booster: 4,000W

Slider touch controls setting

1 bridge area: extended cooking zone (front-left+back-left

position)

9 power levels for each zone

Simmering function

Melting/low-temperature cooking function

Indication of the minimum pan diameter

Residual heat indicator for each zone

Protection against accidental start-up

Automatic safety cut-out

Individual timer for each zone

Child safety lock

Voltage rating: 208/240V - 60Hz

Connected load (nominal power): 6.8/7.4kW

Amps 208/240V: 33Amps

Double 40 Amp breaker required on both sides of line

with ground

• Product family: Cooktop
• Aesthetic: Universale
• Type: Induction
• Dimensions: 30"
• Installation: Ultra-low profile

Dimensions
Width: 31" (78.7 cm) Height: 3.5" (8.9 cm) Depth: 21.5" (54.6 cm)
